MTPX
RFID Readers
This RFID reader features a sleek, slim design with a polycarbonate front panel and a prominent rectangular status LED.
The Wiegand-compatible reader can read credentials at 125 kHz or 13.56 MHz, depending on the model.
Functional design
A beautiful addition to any environment, the reader’s style is the ideal blend of elegance and efficiency.
Scope
MTPX-MF reads Mifare Classic, Ultralight, and DESFire cards with a range of up to 6 cm.
MTPX-EH reads EM4002/4100 and HID 125 kHz compatible cards with a range of up to 5 cm.
General features
- Mounting: Surface
- Housing: ABS
- Internal buzzer: With adjustable intensity using software
- Visible signal: Large LED (green, red, orange)
- Communication: Wiegand
- Tamper protection: Yes
- Wiring: 0.5m cable
- Operating voltage: 9 - 14 V DC
- IP rating: 65
- Temperature: -20ºC to +50ºC
Features per reference
| Reference | Functions and credentials | |
|---|---|---|
| 125 kHz EM/HID (EM4002/4100; HID) | 13.56 MHz (ISO 14443-A (Mifare), NFC CSN) | |
| MTPX-EH | ✓ | — |
| MTPX-MF | — | ✓ |
Downloads
MTPX_Data Sheet_Rev. 1_EN
